The Mega-Power Series (Industrial & Stadium)

Description

Unrivaled Power for Massive Spaces

At Shantis Designs Solar, we reserve the ALLTOP 3000W Titan for projects that require maximum lumen output over vast distances. While standard floodlights struggle to cover a small backyard, the 0293C is designed to sit on high masts, pushing a daylight-bright beam across entire sports fields or industrial compounds. It isn’t just a light; it is a high-capacity power station that operates completely off-grid.

Key Performance Features:

• 1,000 LED “Super-Array”: Utilizing an incredible count of 1,000 high-efficiency 5730 LED chips, this light delivers a massive 480,000 lumens (theoretical max) with a real-world efficacy of 160 lm/w.

• Massive 65AH Energy Reservoir: Equipped with a 3.2V 65,000mAh (65AH) LiFePO4 battery, the largest in its class. This enables a discharging time of 30–36 hours, providing security even through three consecutive days of heavy rain or cloud cover.

• 90W Industrial Solar Engine: The oversized 6V 90W Polycrystalline panel ensures that even a massive battery can be replenished in just 6–8 hours of sunlight, maximizing energy harvest in the Kenyan climate.

• HIPS + Die-Cast Heat Management: To handle the power of 1,000 LEDs, the housing uses specialized high-impact materials and a thermal-conductive design that dissipates 90% of heat, extending the LED lifespan to over 50,000 hours.

• Intelligent Remote Management: Switch between Full Brightness Mode, Smart Motion Sensing (to conserve energy), or set specific Timers for industrial shifts.

• IP65 Extreme Weather Protection: Fully protected against lightning surges, heavy tropical storms, and dust. The 180° adjustable heavy-duty bracket allows for secure mounting on poles or high walls.

Technical Specifications:

• Model: ALP 0293C3000-01

• Rated Power: 3000W

• LED Configuration: 1,000 PCS (5730 LED)

• Solar Panel: 6V / 90W Polycrystalline

• Battery: LiFePO4 3.2V 65AH

• Luminous Efficiency: 160 lm/w

• Charging Time: 6–8 Hours

• Discharging Time: 30–36 Hours (3 Nights Backup)

• Product Size: 550mm x 440mm x 121.7mm

• Installation Height: 8–12 Meters (Recommended)

• Warranty: 3 Years
